Alphie 2 Liter Manual Powder Blender


The motion of Alphie mixer is based on the kinematic inversion principle. The unusual, three-dimensional mixing motion quickly and efficiently produces a homogeneous substance regardless of specific weight of the substances being mixed. This makes it an ideal powder blender or liquid mixer.

Manual Alphie Mixer brings same technology power – generating rhythmic and pulsating movement controlled naturally by hand. Added with the mobility!

Typical applications

It is ideal for use in R & D laboratories, educational institutes, small batch production industry, food/nutrition, pharmaceuticals, metal powder, resin and plastic powder, restaurants, bars and kitchens, bakery, spices, concentrates and many more applications

PRODUCT ADVANTAGES

  • Homogeneous 3D Powder Mixing
  • Gentle, Low-Shear Blending
  • Reduced Cross-Contamination
  • Faster Cleaning and Changeover
  • Ideal for Small-Batch R&D
  • Repeatable Process Control
  • Compact Tabletop Design
  • Suitable for Difficult Powder Blends
  • Multiple Container Options
  • Scale-Up Friendly



TYPICAL APPLICATIONS

Pharmaceutical Powders
Metal Powders
Ceramic Powders
Battery Material Powders
Food and Nutraceutical Powders

MANY CONTAINERS, MULTIPLE OPTIONS

The Alphie 2.5 Liter Powder Blender is designed to work with a wide range of interchangeable containers, from small vials and sample bottles up to 2.5 liter effective capacity blending vessels. This flexibility allows laboratories to process very small R&D samples, formulation trials, and larger laboratory batches using the same mixing platform. Containers can be supplied in multiple materials to match the application, including plastic, glass, and several grades of stainless steel. For stainless steel vessels, multiple polishing and surface-finish options are available, including finishes suitable for applications requiring cleanability, corrosion resistance, or electro-polished product-contact surfaces. By blending material inside a dedicated removable container, each batch remains isolated from the machine and from previous formulations, helping reduce cleaning time, protect sample integrity, and minimize the risk of cross-contamination between batches.

FUNCTIONAL PRINCIPAL

The Alphie 2.5 Liter Powder Blender operates using a 3D inversion mixing principle, where the sealed mixing container moves through a multi-directional tumbling motion to continuously reposition the powder bed. Instead of using internal blades, paddles, or agitators, the material is gently blended inside a detachable container as it rotates and inverts through changing angles. This motion helps powders, granules, liquids, and suspensions achieve a uniform blend while reducing shear, minimizing product contact with the machine, and lowering the risk of cross-contamination between batches.

TECHNICAL DATA

Capacity (L)

2

Max mixing mass (kg)

2

Overall Dimensions

350 mm Wide x 320 mm Deep x 250 mm Height

Max Container / Bottle Size

Dia 115 mm x 210 mm Long

Total Weight

9.0 kg
