PRODUCT ADVANTAGES
Throughput
•1100 ml (1.0 kg) x 2 cups
Function
• Individual rotation and revolution control.
• Step operation to help with stubborn materials.
• Vacuum assist for degassing and defoamin.
Containers and Adapters
The Kakuhunter mixer can accommodate multiple container sizes and shapes, giving users flexibility when processing different material volumes, viscosities, and application requirements. By using the proper adapter, materials can be mixed and degassed in small jars, syringes, cups, bottles, and specialty containers without needing to transfer the material between vessels. This helps reduce material loss, minimize contamination risk, and improve workflow efficiency.
The ability to use different container formats makes the system suitable for a wide range of applications, from small-scale R&D samples to larger laboratory batches, while maintaining consistent mixing, dispersion, and bubble removal performance.
APPLICATION EXAMPLES
EASY TO USE TOUCH PANEL
The touchscreen interface is designed for simple, intuitive operation. Users can touch the field they want to edit and enter values directly, making setup faster and easier. Speed settings, operating time, and other numerical parameters can be entered using a pop-up numeric keypad, eliminating the need to move a cursor with buttons or scroll through values manually.
This streamlined input method improves usability, reduces setup time, and helps operators enter process conditions more accurately.
MONITOR PROCESSING DATA
OPTIONAL NON-CONTACT TEMPERATURE SENSOR
The optional Kakuhunter Temperature Monitoring System allows users to measure and monitor material temperature in real time during the mixing process. This accessory helps improve process control, supports repeatable results, and provides added protection for temperature-sensitive materials.
- Measures and monitors material temperature while mixing
- Displays real-time temperature data from the integrated temperature sensor
- Provides alarm notifications when the measured temperature exceeds the preset upper or lower limit
- Allows measured temperature data to be exported in CSV format for recordkeeping and analysis
- Compatible with 300 mL, 400 mL, and 1100 mL containers
Recommended for When:
· Materials are damaged by temperature rises.
· Materials harden with temperature rises.
· The composition of materials changes or their components volatilize, etc.
What’s Included
TECHNICAL DATA
| Cup size | 1100ml x 2cups Various syringes of 100cc or less Various barrels of 170cc or less |
|
| Max throughput | 1kg x 2cups | |
| Other containers | A variety of containers and syringes can be used by use of an adapter | |
| Cup tray | Straight: SK-1100TVIII Shifted: SK-1100TVSIII |
|
| Speed of revolution | Settable at 9 steps | |
| Speed of rotation | Settable at 10 steps | |
| Settable time | Maximum 25 minutes (5 step total) | |
| Step mode | 5 steps Continuous operation can be performed with 5 different types of operation patterns (condition settings) |
|
| Conditions setting memory | User-settable channels | 90 CH |
| Fixed data channels | 10 CH | |
| Power supply voltage | Three-phase 200-240V Three-phase 380-415V 50/60Hz |
|
| Power consumption | 3.0kW | |
| External dimensions | W732 x D820 x H836 (mm) (excluding external vacuum pump) | |
| Weight of the main unit | Approx. 260 kg (excluding external vacuum pump) | |
* It differs machine throughput depending on materials characteristic.
* Revolving speed may change depending on materials characteristic.
* Detailed specification may change without prior notice.
