PRODUCT ADVANTAGES
Throughput
•2000 ml (2.0 kg) x 2 cups
Function
• Individual rotation and revolution control.
• Step operation to help with stubborn materials.
Containers and Adapters
The Kakuhunter mixer can accommodate multiple container sizes and shapes, giving users flexibility when processing different material volumes, viscosities, and application requirements. By using the proper adapter, materials can be mixed and degassed in small jars, syringes, cups, bottles, and specialty containers without needing to transfer the material between vessels. This helps reduce material loss, minimize contamination risk, and improve workflow efficiency.
The ability to use different container formats makes the system suitable for a wide range of applications, from small-scale R&D samples to larger laboratory batches, while maintaining consistent mixing, dispersion, and bubble removal performance.
APPLICATION EXAMPLES
OPTIONAL NON-CONTACT TEMPERATURE SENSOR
The optional Kakuhunter Temperature Monitoring System allows users to measure and monitor material temperature in real time during the mixing process. This accessory helps improve process control, supports repeatable results, and provides added protection for temperature-sensitive materials.
- Measures and monitors material temperature while mixing
- Displays real-time temperature data from the integrated temperature sensor
- Provides alarm notifications when the measured temperature exceeds the preset upper or lower limit
- Allows measured temperature data to be exported in CSV format for recordkeeping and analysis
- Compatible with 300 mL, 400 mL, and 1100 mL containers
Recommended for When:
· Materials are damaged by temperature rises.
· Materials harden with temperature rises.
· The composition of materials changes or their components volatilize, etc.
What’s Included
TECHNICAL DATA
| Cup size | User designated (up to approx. 2000ml x 2 cups) | |
| Max throughput | 2kg x 2 cups | |
| Other containers | A variety of containers and syringes can be used by use of an adapter | |
| Speed of revolution | Settable at 9 steps | |
| Speed of rotation | Settable at 10 steps | |
| Setup time | Maximum 25 minutes (5 step total) | |
| Step mode | 5 steps
Continuous operation can be performed with 5 different types of operation patterns (condition settings) |
|
| Conditions setting memory | User-settable channels | 90CH |
| Fixed data channels | 10CH | |
| Power supply voltage | Three-phase 200-240V Three-phase 380-415VA 50/60Hz |
|
| Power consumption | 2.5kW | |
| External dimensions | W646×D663×H851（㎜） | |
| Weight of the main unit | Approx. 225kg | |
* It differs machine throughput depending on materials characteristic.
* Revolving speed may change depending on materials characteristic.
* Detailed specification may change without prior notice.
